High-Performance Mass Spectrometers
Linear Time-of-Flight Mass Spectrometer
The ClinMS-Plat® I Time-of-Flight Mass Spectrometer consists of a main unit (including ion source module, detector module, flight tube, frame module, housing, and vacuum pump) and software. Utilizing MALDI-TOF technology, this product, in conjunction with compatible reagents, is designed for the acquisition of peptide or protein fingerprint profiles from human serum samples. It is the first clinical mass spectrometer (Zhejiang Medical Device Registration No. 20242221307) approved for serum peptide or protein fingerprint analysis.
Product Consultation
Fast: Unique peptide enrichment technology, automated batch detection, completing 96 samples in 40 minutes.
Stability: Quality control technology ensures low variation in peptide/protein peak intensities, delivering high reproducibility and stability
Sensitive: Detection limits for relevant peptides reach fmol/μL levels
Precision: Accurate: Detects multiple markers in peptide and protein fingerprint profiles, offering more reliable results compared to single or limited marker combinations
-Sample Types: Serum (preferred), plasma, urine, tissue, cells, etc.
-Targets: Peptide and protein fingerprint profiling
-Applications: Screening, auxiliary diagnosis, and evaluation of tumor recurrence and metastasis for various diseases, including cancer, urinary system disorders, and neurological conditions.
Mass Range
Optimal Mass Resolution
Sensitivity
Mass Accuracy
Mass Repeatability
Mass Stability
680~18600Da
≥700
Molecular Weight Calibrator SNR ≥10
≤500 ppm
≤0.03%
≤3×10-4
