Supporting Equipment
Fully Automated Sample Preprocessing Workstation
ClinASP II Fully Automated Sample Pretreatment Workstation features an automated pipetting workflow, a sample temperature control module, and a full-chamber humidity control module. As a customized solution, it enables high-precision, high-throughput sample preparation and spotting. ClinASP II is typically used with high-throughput MALDI-TOF mass spectrometers, significantly reducing manual workload while improving processing efficiency and detection accuracy.
Product Consultation
High Efficiency: Supporting up to 12-sample simultaneous pipetting and spotting with a minimum sample volume of 5 μL. Ideal for metabolomics and lipidomics preparation of limited clinical samples, significantly enhancing efficiency
High Precision: Ensures accurate spatial positioning with a pipetting volume deviation of <10% for micro-samples and <5% for larger volumes. Programmable for handling omics preprocessing reagents such as isopropanol, methanol, and ethers, with no wall adhesion or droplet formation issues.
High Stability: Features sample temperature control and full-process humidity regulation, ensuring a stable and reproducible preprocessing and spotting environment. Particularly suitable for metabolomics analyses which is sensitive to temperature and humidity variations during sample preparation
User-Friendly Operation: Users can easily edit workflows according to the sample preparation steps, integrating key preprocessing and spotting stages into a single device for quick transitions between processes
Used in conjunction with high-throughput MALDI-TOF mass spectrometers to greatly reduce manual operation, improve pretreatment and sampling efficiency and detection accuracy.
Flux
Spotting Rate
Pipetting Volume
Pipetting Accuracy
8/12 Channels
3-4min/108 Well
0.5~12.5μL/ 5~125μL
1.25μL，≤10% 6.25μL，≤5% 62.5μL，≤2.5%
